| Length | 25 |
| Cover Color | Black |
| Cover Material | Chloroprene - Type A |
| Cover Type | Type A - Corrugated - Flame Resistant |
| Material | Chloroprene - Type A |
| Outside Diameter | 1.66 |
| Burst Pressure | 1000 |
| Maximum Working Pressure | 250 |
| Hose Material | Nitrile - Type C |
| Reinforcement Material | Synthetic, High Tensile Textile Reinforcement w/ Steel Wire Helix |
| Temperature Rating | -40 Deg. F to +275 Deg. F (-40 Deg. C to +135 Deg. C), Do Not Convey Fuels Over +120 Deg. F |
| Color | Black |
| Inside Diameter | 1.25 |
| Hose Pressure Description | Low Pressure |
| Minimum Burst Pressure (psi) | 1000 |
| Type | Hydraulic Hose |
| Hose Inside Diameter (in) | 1.25 |
| Maximum Working Pressure (psi) | 250 |
| Minimum Bend Radius (in) | 1.3 |
| Hose Outside Diameter (in) | 1.66 |
| Inside Diameter (in) | 1.25 |
| Tube Material | Nitrile - Type C |
| Product Type | Multi Master GMV Megaflex Return Line & Suction Hose - SAE 100R4 |
| Temperature Range | -40 Deg. F to +275 Deg. F (-40 Deg. C to +135 Deg. C), Do Not Convey Fuels Over +120 Deg. F |
| Industrial Description | MULTI MASTER 20GMV MEGAFLEX 1 1/4X25FT |
| Reinforcement | Synthetic, High Tensile Textile Reinforcement w/ Steel Wire Helix |
| Coupling Recommendation | GL, Clamp over Beaded Nipple |
| Heavy Duty Supplier | Yes |
| ISO Specification | N/A |
| EN Specification | N/A |
| Dash Size | 20 |
| SAE Specification | 100R4 |
| Tube Description | Black |
| Outside Diameter (In) | 1.66 |
| Alliance Keywords | hydraulic hose, hydraulic fitting, hydraulic coupler, Boyau hydraulique, Accouplement |
| Part Terminology | Hydraulic Hose |
