| Grade Type | Electro-Viscous |
| Thermal Or Centrifugal | D - Severe Duty & Truck Fan Drive |
| Terminal Type | Female |
| Distance From Clutch To Mounting Flange | 2.62 |
| Clutch Maximum Diameter | 7.73 |
| Wire Gauge Measurement | Uses Original Equipment Connector |
| Rotation | REV |
| Mounting Type | HEX |
| Mounting Hole Quantity | 4 |
| Wire Quantity | Uses Original Equipment Connector |
| Color | Raw Aluminum in Color |
| Use Type | Electro-Viscous |
| Bolt Hole Quantity | 4 |
| Material | Aluminum |
| Clutch Type | D - Severe Duty & Truck Fan Drive |
| O.E. Replacement? | Yes |
| New or Reman | New |
| Meets / Exceeds OEM? | Yes |
| SDS Required | No (135233618) |
| Mount Hole Qty | 4 |
| Performance Rated? | Yes |
| Mounting Hardware? | Not Included |
| Pilot Depth MM | 17.8 |
| Style | Severe Duty |
| Drawing Type | D |
| Bolt Quantity | 4 |
| Mount Type | HEX |
| Description | Fan Clutches |
| Bolt Thread | M6 x 1.0 Hole |
| Overall Height MM | 90.9 |
| Type | Electronic |
| Duty Rating | Electro-Viscous |
| Overall Dia. MM | 196.3 |
| Fan Mount Dia. MM | 163.8 |
| Fan Bolt Circle MM | 178 |
| Fan Mount Height MM | 66.5 |
| Fan Bolt Circle IN | 7.01 |
| Electronic Clutch? | Electronic |
| Warranty | 1 year/12,000 miles |
| Dia. IN | 7.73 |
| Pilot Dia. MM | 30 |
| Pilot Dia. IN | 1.18 |
| Mount Dia. MM | 36 |
| Mounting Hardware Included | No |
| Pilot Depth IN | 0.7 |
| Overall Height IN | 3.58 |
| Fan Mount Dia. IN | 6.45 |
| Overall Dia. IN | 7.73 |
| Mount Dia. IN | 1.44 |
| Part Terminology | Engine Cooling Fan Clutch |
