| Design | Single Row Radial |
| Type | A-5 |
| Part Description | Ball Bearing |
| Outer Race Radius (Inch) | 0.040 |
| Inner Race Radius (Inch) | 0.040 |
| Outer Race Radius (MM) | 1.016 |
| Inner Race Radius (MM) | 1.016 |
| Footnote | Agricultural Bearing Special |
| Series | AGSPEC |
| Bore (Inch) | 0.750 |
| Bore (MM) | 19.050 |
| Inner Race Bore (Inch) | 0.750 |
| Inner Race Bore (MM) | 19.050 |
| Inner Race Width (MM) | 15.494 |
| Outer Race Width (MM) | 15.494 |
| Outside Diameter (Inch) | 1.781 |
| Width (inch) | 0.610 |
| Outer Race Outside Diameter (Inch) | 1.781 |
| Outer Race Width (Inch) | 0.610 |
| WIDTH (MM) | 15.494 |
| Inner Race Width (Inch) | 0.610 |
| Outside Diameter (MM) | 45.225 |
| Outer Race Outside Diameter (MM) | 45.225 |
| Heavy Duty Supplier | Yes |
| Part Terminology | Multi-Purpose Bearing |
