| Design | Single Row Radial |
| Part Description | Ball Bearing |
| Type | A-1 |
| Bore (Inch) | 1.378 |
| Bore (MM) | 35.000 |
| Inner Race Bore (Inch) | 1.378 |
| Inner Race Bore (MM) | 35.000 |
| Series | 300 |
| Outside Diameter (Inch) | 3.150 |
| Outer Race Outside Diameter (Inch) | 3.150 |
| Outside Diameter (MM) | 80.000 |
| Outer Race Outside Diameter (MM) | 80.000 |
| Outer Race Radius (Inch) | 0.060 |
| Outer Race Radius (MM) | 1.520 |
| Inner Race Radius (MM) | 1.520 |
| Inner Race Radius (Inch) | 0.060 |
| Inner Race Width (MM) | 21.000 |
| Outer Race Width (MM) | 21.000 |
| Width (inch) | 0.827 |
| Outer Race Width (Inch) | 0.827 |
| WIDTH (MM) | 21.000 |
| Inner Race Width (Inch) | 0.827 |
| Heavy Duty Supplier | Yes |
| Part Terminology | Multi-Purpose Bearing |
