| Solid Or Vented Type Rotor | Vented |
| Nominal Thickness | 1.102 |
| Outside Diameter | 11.89 |
| Discard Thickness | 26.4 |
| Mounting Bolt Hole Quantity | 5 |
| Overall Height | 55.0 |
| Heavy Duty Supplier | Yes |
| Center Hole Diameter Inches | 2.835 |
| Overall Height Inches | 2.165 |
| VIO | 1637535 |
| Rotor Type | Vented |
| Bolt Holes | 5 |
| Center Hole Diameter MM | 72 |
| Outer Diameter Inches | 11.89 |
| Outer Diameter MM | 302 |
| Bolt Circle Diameter MM | 127 |
| Bolt Circle Diameter Inches | 5 |
| Overall Height MM | 55 |
| New Thickness Inches | 1.102 |
| New Thickness MM | 28 |
| Minimum Thickness MM | 26.4 |
| Minimum Thickness Inches | 1.039 |
| California Proposition 65 | Warning: Cancer and Reproductive Harm – www.P65Warnings.ca.gov |
| Part Terminology | Disc Brake Rotor |
