| Heavy Duty Supplier | Yes |
| Bottom Hose Fitting (in) | 1 1/4 Right |
| Tech Note | O.E.M. style Plastic tanks & Aluminum core;Multifit model supplied with pressure cap. |
| Core Width (in) | 26 11/16 |
| Core Length (IN) | 13 3/4 |
| Inlet Length (In) | 27 1/4 |
| Top Hose Fitting (in) | 1 1/4 Centre |
| Core Width | 26 11/16 |
| Csf Cap Number | 4514 |
| Core Material | Aluminum |
| Inlet Diameter | 1 1/4 Centre |
| Down Flow Or Cross Flow Type | Down Flow |
| Cap Included | Yes |
| Tank Material | Plastic |
| Box Height (in) | 5 4/16 |
| Oil Cooler (in) | 12 13/16 (high-effeciency Concentric Type) |
| Box Weight (lbs) | 8 |
| Outlet Length (In) | 27 1/4 |
| Outlet Diameter | 1 1/4 Right |
| No. of Rows | 1 |
| Hazardous Material | No |
| Core Thickness | 5/8 |
| Outlet Width (in) | 1 5/8 |
| Radiator Core Row Quantity | 1 |
| Inlet Width (in) | 1 1/16 |
| Heavy Duty | Yes |
| Core Length | 13 3/4 |
| Cross-flow/ Down-flow | Down Flow |
| Box Width (in) | 20 |
| Box Length (in) | 29 1/4 |
| Core Thickness (in) | 5/8 |
| Radiator Cap Supplied | Yes |
| Part Terminology | Radiator |
