M2T MegaFlex 2-Wire Braid Hose - SAE 100R16
Part # 70261 | Line Code: GAT
brandNameImage
brandNameImage

$18.99
$18.99
error
Not Fitted

Product Details
expand_less
Inside Diameter .5
Cover Color Black
Length 100
Cover Type Type C2 - Flame, Oil, Abrasion & Weather Resistant
Material Synthetic Rubber - Modified Nitrile - Type C2 - Color Coded Layline
Cover Material Synthetic Rubber - Modified Nitrile - Type C2 - Color Coded Layline
Hose Material Nitrile - Type C
Reinforcement Material Two Braids, High-Tensile Steel Wire
Temperature Rating -40 Deg. F to +212 Deg. F (-40 Deg. C to +100 Deg. C)
Outside Diameter .82
Maximum Working Pressure 4300
Burst Pressure 17200
Color Black
Hose Inside Diameter (in) .5
Temperature Range -40 Deg. F to +212 Deg. F (-40 Deg. C to +100 Deg. C)
Type Hydraulic Hose
Hose Pressure Description High Pressure
Reinforcement Two Braids, High-Tensile Steel Wire
Product Type M2T MegaFlex 2-Wire Braid Hose - SAE 100R16
Coupling Recommendation GlobalSpiral, MegaCrimp, Stainless Steel B
Hose Outside Diameter (in) .82
Industrial Description 8M2TX100REEL
Minimum Bend Radius (in) 2.8
Maximum Working Pressure (psi) 4300
Minimum Burst Pressure (psi) 17200
Inside Diameter (in) .5
Outside Diameter (In) .82
Tube Material Nitrile - Type C
Heavy Duty Supplier Yes
Dash Size 8
ISO Specification 11237 2SC R16, 1436 2SN R2
EN Specification 857 2SC, 853 2SN
SAE Specification 100R16
Tube Description Black, Oil-Resistant, Synthetic Rubber
Alliance Keywords hydraulic hose, hydraulic fitting, hydraulic coupler, Boyau hydraulique, Accouplement
Part Terminology Hydraulic Hose

Features & Benefits
expand_more
M2T hose is recommended for high-pressure hydraulic oil line applications. It has smaller exterior dimensions and significantly tighter bend radius than competitive R16 hoses, making it easy to route and install in tight areas. M2T hose is compatible with biodegradable hydraulic fluids like polyolester, polyglycols and vegetable oils as well as petroleum-based fluids.
