Product Details
expand_less
| Flange Shape |
Triangle |
| Wheel Stud Quantity |
6 |
| Bolt Circle Diameter |
115.000 |
| Wheel Pilot Diameter |
70.100 |
| Brake Pilot Diameter |
70.600 |
| Flange Diameter |
145.500 |
| Hub Pilot Diameter |
91.400 |
| Flange Offset |
42.000 |
| Spline Quantity |
33 |
| Flange Bolt Hole Quantity |
3 |
| Anti Lock Brake Sensor Included |
Yes |
| Heavy Duty Supplier |
Yes |
| Part Terminology |
Wheel Bearing and Hub Assembly |
Features & Benefits
expand_more
Backed by superior materials and rigorous testing, MOOG hub assemblies deliver reliable performance you can count on. MOOG problem-solving innovations ensure fast, hassle-free installation.
Application Summary
expand_more
2006-2007 Buick Terraza (Front, Rear) (Drive: FWD, AWD / Qualifier: Enhanced Hub Assembly - Includes Grime Defense Outboard Seal, Primary Inboard and Outboard Seals, as well as molded grommet for ABS cable); 2006-2009 Chevrolet Uplander (Front, Rear) (Drive: FWD, AWD / Qualifier: Enhanced Hub Assembly - Includes Grime Defense Outboard Seal, Primary Inboard and Outboard Seals, as well as molded grommet for ABS cable); 2006-2009 Pontiac Montana (Front, Rear) (Drive: FWD, AWD / Qualifier: Enhanced Hub Assembly - Includes Grime Defense Outboard Seal, Primary Inboard and Outboard Seals, as well as molded grommet for ABS cable); 2006-2007 Saturn Relay (Front, Rear) (Drive: FWD, AWD / Qualifier: Enhanced Hub Assembly - Includes Grime Defense Outboard Seal, Primary Inboard and Outboard Seals, as well as molded grommet for ABS cable)
