| Solid Or Vented Type Rotor | Vented |
| Nominal Thickness | 39.0 |
| Outside Diameter | 369.0 |
| Discard Thickness | 1.472 |
| Mounting Bolt Hole Quantity | 10 |
| Overall Height | 98.5 |
| Heavy Duty Supplier | Yes |
| Center Hole Diameter Inches | 5.087 |
| Bolt Circle Diameter Inches | 6.693 |
| Outer Diameter Inches | 14.528 |
| Overall Height Inches | 3.878 |
| VIO | 235106 |
| Rotor Type | Vented |
| Bolt Holes | 10 |
| Center Hole Diameter MM | 129.2 |
| Bolt Circle Diameter MM | 170 |
| New Thickness Inches | 1.535 |
| New Thickness MM | 39 |
| Minimum Thickness MM | 37.4 |
| Outer Diameter MM | 369 |
| Minimum Thickness Inches | 1.472 |
| Overall Height MM | 98.5 |
| California Proposition 65 | Warning: Cancer and Reproductive Harm – www.P65Warnings.ca.gov |
| Part Terminology | Disc Brake Rotor |
